Product Description

1050 1060 1070 Corrugated Aluminum Sheet

1)Alloy: 1050, 1060, 1070 or 1100
2)Temper: H14, H18, H22, H24
3)Width: 800mm-1300mm
4)Thickness: 0.8mm-3.0mm

Product
Aluminium corrugated roofing sheet
Recommend material
1050, 1060, 1070, 1100
Temper
H12, H14, H16, H18, H19, H22, H24, H26
Material
CC material
Surface
Plain surface(prepare for painting and corrugating)
Color
Sliver(Withour painting color)
Width
900mm-1300mm
Thickness
0.1mm-3.0mm
Application
Roofing, indoor and outdoor windows, show box, observe window, carport, awning, indoor partition, advertisement panel, sound barrier

Chemical Content
Alloy	Si	Fi	Cu	Mn	Mg	Cr	Ni	Zn	Ti	Single	Total	Al
1050	0.25	0.40	0.05	0.05	0.05	_	_	0.05	0.03	0.03	_	99.5
1060	0.25	0.35	0.05	0.03	0.03	_	_	0.05	0.03	0.03	_	99.6
1070	0.20	0.25	0.04	0.03	0.03			0.04	0.03	0.03		99.7
1100	0.95		0.05-0.20	0.05	_	_	_	0.10	_	0.05	0.14	99.00
3003	0.6	0.7	0.05-0.20	1.0-1.5	_	_	_	0.10	_	0.05	0.15	_
5005	0.30	0.70	0.20	0.20	0.50-1.1	0.10	_	0.25	_	0.05	0.15	_
8011	0.50-0.90	0.6-1.0	0.1	0.2	0.05	0.05	_	0.10	0.08	0.05	0.15	_

Model	Style	Alloy	Temper	Specification(mm)
				Wave height	Wave Length	Thickness	Width	Length
SW25-150i	As picture1	1050 1060 1070 1100 3003 5005 8011	H18	25	150	0.6-1.0	635	1700--6200
SW25-150ii	As picture2						935
SW25-150iii	As picture3						970
SW25-150iv	As picture4						1170
SW60-137.5	As picture5		H16,H18	60	187.5	0.9_1.2	826	1700--6200
SW25-300	As picture6		H16	25	300	0.6_1.0	985	1700--5000
SW35-115i	As picture7		H16,H18	35	115	0.7_1.2	720	>=1700
SW35-115ii	As picture8						710
SW35-125	As picture9		H16,H18	35	125	0.7_1.2	807	>=1700
SW130-550	As picture10		H16,H18	130	550	1.0_1.2	625	>=6000
SW173	As picture11		H16,H18	173	_	0.9_1.2	387	>=1700
SW295	As picture12		H18	_	_	0.6_1.0	295	1200--2500
