Mil-Tdl-46027K 5083 5059 H131 H136 H116 H321 Aluminum Alloy Armor Plate
5083 5059 5456 7039 7B52 7085 H131 H116 H321 aluminum armor sheet plateAluminum armor sheet plate is often used for amphibian and other armored vehicles in corrosive environments. With the ever-increasing need to extend the life cycles of current and future military platforms, the outstanding corro......
Send Inquiry
Product Description
5083 5059 5456 7039 7B52 7085 H131 H116 H321 aluminum armor sheet plate
Aluminum armor sheet plate is often used for amphibian and other armored vehicles in corrosive environments. With the ever-increasing need to extend the life cycles of current and future military platforms, the outstanding corrosion resistance and excellent ballistic protection of continues to play a critical role in the defense industry.
Main alloy:5083 5059 5456 7039 7B52 7085
Temper:H131 H116 H321 H32 T711
Thickness:6.35mm to 76.2mm
Standard:MIL-TDL-46027,MIL-DTL-46063
5083 Aluminum Alloy Armor Plate
7A52 Aluminum Alloy Armor Plate
7A52 aluminum alloy plate which belongs to the Al - zinc - Mg, is a heat treatment alloy with high specific strength and high fracture toughness and low cycle fatigue resistance.It is the only high strength ,weldable alloy listed in the domestic military standard.The alloy as gun carriage and armor structure is widely used in weapon industrial field.
Properties of 7A52 aluminum alloy plate
(1) The surface of 7A52 aluminum alloy is well formed after welding, resulting in small spatter and no welding defects such as biting, pores and cracks;
(2) The tensile strength of the welded joint of 7A52 aluminum alloy is 274.8mpa. The joint coefficient is 0.58.
(3) The welded joint of 7A52 aluminum alloy has good bending performance without cracks and other defects;
(4) 7A52 aluminum alloy has good weldability;
7085 Aluminum Alloy Armor Plate
Our Aluminum plate represent the optimum solution for any kind of structural application - with specific ballistic performance, if required. Armor & ballistic aluminium plate can be utilized in the manufacture of military vehicles, structural housings with high protection, armaments and other protective structures and varied applications.
Package:wooden pallet
Aluminum armor sheet plate is often used for amphibian and other armored vehicles in corrosive environments. With the ever-increasing need to extend the life cycles of current and future military platforms, the outstanding corrosion resistance and excellent ballistic protection of continues to play a critical role in the defense industry.
Main alloy:5083 5059 5456 7039 7B52 7085
Temper:H131 H116 H321 H32 T711
Thickness:6.35mm to 76.2mm
Standard:MIL-TDL-46027,MIL-DTL-46063
5083 Aluminum Alloy Armor Plate
| Thickness (inches) | Description | Width (inches) | Length (inches) | Specs |
| 1.25 | 5083 H131 ARMOR PLT 1.25 (+-.047) | 48.50", 60.50" | 144.50" | MIL - DTL - 46027k (2) 2015 ROHS Compliant |
| 1.5 | 5083 H131 ARMOR PLT 1.5 (+-.047) | 48.50", various | 144.50" | MIL - DTL - 46027k (2) 2015 ROHS Compliant |
| 1.75 | 5083 H131 ARMOR PLT 1.75 (+-.060) | various | 144.50" | MIL - DTL - 46027k (2) 2015 ROHS Compliant |
| 2 | 5083 H131 ARMOR PLT 2 (+-.060) | 48.50", various | 144.50" | MIL - DTL - 46027k (2) 2015 ROHS Compliant |
| 2.25 | 5083 H131 ARMOR PLT 2.25 (+-.060) | 48.50", 60.50", various | 144.50" | MIL - DTL - 46027k (2) 2015 ROHS Compliant |
| 2.5 | 5083 H131 ARMOR PLT 2.50 (+-.085) | 48.50" | 144.50" | MIL - DTL - 46027k (2) 2015 ROHS Compliant |
| 3 | 5083 H131 ARMOR PLT 3 (+-.075) | various | 144.50" | MIL - DTL - 46027k (2) 2015 ROHS Compliant |
7A52 Aluminum Alloy Armor Plate
7A52 aluminum alloy plate which belongs to the Al - zinc - Mg, is a heat treatment alloy with high specific strength and high fracture toughness and low cycle fatigue resistance.It is the only high strength ,weldable alloy listed in the domestic military standard.The alloy as gun carriage and armor structure is widely used in weapon industrial field.
Properties of 7A52 aluminum alloy plate
(1) The surface of 7A52 aluminum alloy is well formed after welding, resulting in small spatter and no welding defects such as biting, pores and cracks;
(2) The tensile strength of the welded joint of 7A52 aluminum alloy is 274.8mpa. The joint coefficient is 0.58.
(3) The welded joint of 7A52 aluminum alloy has good bending performance without cracks and other defects;
(4) 7A52 aluminum alloy has good weldability;
7085 Aluminum Alloy Armor Plate
| Thickness (inches) | Description | Width (inches) | Length (inches) | Specs |
| 1 | 7085 T711 ARMOR PLT 1 (+-.047) | 60.50" | 144.50" | MIL - DTL - 32375 type A ROHS Compliant |
| 1.25 | 7085 T711 ARMOR PLT 1.25 (+-.047) | 60.50" | 144.50" | MIL - DTL - 32375 type A ROHS Compliant |
| 1.5 | 7085 T711 ARMOR PLT 1.5 (+-.047) | 60.50" | 144.50" | MIL - DTL - 32375 type A ROHS Compliant |
| 2.5 | 7085 T711 ARMOR PLT 2.5 (+-.060) | 60.50" | 144.50" | MIL - DTL - 32375 type A ROHS Compliant |
Our Aluminum plate represent the optimum solution for any kind of structural application - with specific ballistic performance, if required. Armor & ballistic aluminium plate can be utilized in the manufacture of military vehicles, structural housings with high protection, armaments and other protective structures and varied applications.
Package:wooden pallet
