3mm Titanium Sheet Grade 5 Ti6al4V Cervical Titanium Plate Sheet

Product Description

Xi'an baoti Materials Co.,Ltd is leading titanium and titanium alloy supplier, manufacturer and distributor. We specialized in the sales of high quality titanium and its alloy products like tube, pipes, bar, rods, sheets, plates. Located in Baoji, the titanium valley of China, we manufactured and supplied titanium products with factory price and trustworthy quality.

Titanium and titanium alloy have been widely used in many challenging applications like Aerospace, Medical, Industrial, and Oil and Gas industries due to its unique combination of high strength, light weight, corrosion resistance, biocompatibility, and higher temperature performance. Our Titanium round bar meets numerous AMS, ASTM, NACE, EN, and MIL specifications and various grades available in Titanium CP Grade 1, Grade 2, Grade 4, Grade 5 6Al-4V, Grade 23 6Al-4V ELI, and 6Al-2Sn-4Zr-6Mo.

3mm Titanium Sheet Grade 5 Ti6al4V Cervical Titanium Plate Sheet

	Specification	ASTM B265, ASME SB265 AMS 4928 AMS 2631, AMS 4901, AMS 4907, AMS 4911 MIL-T: MIL-T-9046, MIL-T-9046 CP1 EN: EN 10204.3, EN 1-204:2005 3.1 NACE: NACE MR0175 DIN 17860 JIS H4600
	Grades	Commercially Pure Titanium Grade 2 CP 3 \| UNS R50400 Grade 4 CP 1 \| UNS R50700 Titanium Alloys 6Al-4V Grade 5 \| UNS R56400 6Al-2SN-4ZR-2MO \| UNS R54620 6Al-4V Grade 5 STA \| UNS R56400 7Al-4Mo \| UNS R56740 6Al-4V ELI Grade 23 \| UNS R56407 Grade 7 \| UNS R52400 6Al-6V-2SN \| UNS R56620
	Size:	W.T: 3-70mm Width:400-3000mm L: ≤6000mm
	Applications	Medical, Aerospace, Military, Medical. Petrochemical engineering, Metallurgy, eElectroplating, Vacuuming metalling, Sports goods and so on.
	Machining ability/Our services	CNC turning, CNC milling, Wire EDM machining, CNC grinding and more
	Quality control	100% critical inspection before packing Titanium bar is tested by our local authorized non-ferrous metal institution for its chemical and machnical compositions, ultrosonic test, granulations test, etc.
	Surface	Polish, Grounded, Peeled, etc.

OTHER PRODUCTS WE WUPPLYING

3mm Titanium Sheet Grade 5 Ti6al4V Cervical Titanium Plate Sheet

Grades	UNS No	N	C	H	Fe	O	Al	V	Pd	Mo	Ni
GR 1	R50250	0.03	0.08	0.015	0.2	0.18
GR 2	R50400	0.03	0.08	0.015	0.3	0.25
GR 3	R50550	0.05	0.08	0.015	0.3	0.35
GR 4	R50700	0.05	0.08	0.015	0.5	0.4
GR 5	R56400	0.05	0.08	0.015	0.4	0.2	5.5-6.75	3.5-4.5
GR 7	R52400	0.03	0.08	0.015	0.3	0.25			0.12-0.25
GR 9	R56320	0.03	0.08	0.015	0.25	0.15	2.5-3.5	2.0-3.0
GR 12	R53400	0.03	0.08	0.015	0.3	0.25				0.2-0.4	0.6-0.9
GR 23	R56401	0.03	0.08	0.0125	0.25	0.13	5.5-6.5	3.5-4.5
