En10025 S355jr S355j0 S355j2 S275jr S275j0 S275j2 Steel Construction H I Section Beam
Product name:EN10025 S355JR S355J0 S355J2 S275JR S275J0 S275J2 Steel construction H I section beamSize:Standard H beam In StockSize(mm)Weight per meter(kg/m)Size(mm)Weight per meter(kg/m)Size(mm)Weight per meter(kg/m)Size(mm)Weight per meter(kg/m)Size(mm)Weight per meter(kg/m)100*100*6*817.2294*200*......
Send Inquiry
Product Description
Product name:EN10025 S355JR S355J0 S355J2 S275JR S275J0 S275J2 Steel construction H I section beam
Size:
Standard:AISI,ASTM,BS,DIN,GB,JIS,etc.
Material:S355JR,S355J0H,S355J2H,etc
Application:
1.Industrial structure of the steel structure bearing bracket.
2.Underground engineering steel pile and retaining structure.
3.Petrochemical and electric power and other industrial equipment structure
4.Large span steel bridge components
5.Ships, machinery manufacturing frame structure
6.The train, automobile, tractor beam bracket
7.Port of conveyor belt, high speed damper bracket
Size:
| Standard H beam In Stock | |||||||||
| Size(mm) | Weight per meter(kg/m) | Size(mm) | Weight per meter(kg/m) | Size(mm) | Weight per meter(kg/m) | Size(mm) | Weight per meter(kg/m) | Size(mm) | Weight per meter(kg/m) |
| 100*100*6*8 | 17.2 | 294*200*8*12 | 57.3 | 428*407*20*35 | 284 | 100*63*4.5 | 11.261 | 320*134*13.5 | 62.765 |
| 125*125*6.5*9 | 23.8 | 294*302*12*12 | 85 | 440*300*11*18 | 128 | 120*74*5 | 13.987 | 360*136*10 | 60.037 |
| 148*100*6*9 | 21.4 | 298*149*5.5*8 | 32.6 | 446*199*8*12 | 66.7 | 140*80*5.5 | 16.89 | 360*138*12 | 65.689 |
| 150*75*5*7 | 14.3 | 300*150*6.5*9 | 37.3 | 450*200*9*14 | 76.5 | 160*88*6 | 20.513 | 360*140*14 | 71.341 |
| 150*150*7*10 | 31.9 | 300*300*10*15 | 94.5 | 482*300*11*15 | 115 | 180*94*6.5 | 24.143 | 400*142*10.5 | 67.598 |
| 175*90*5*8 | 18.2 | 300*305*15*15 | 106 | 488*300*11*18 | 129 | 200*100*7 | 27.929 | 400*144*12.5 | 73.878 |
| 175*175*7.5*11 | 40.4 | 340*250*9*14 | 79.7 | 496*199*9*14 | 79.5 | 200*102*9 | 31.069 | 400*146*14.5 | 80.158 |
| 194*150*6*9 | 31.2 | 344*348*10*16 | 115 | 500*200*10*16 | 89.6 | 200*110*7.5 | 33.07 | 450*150*11.5 | 80.42 |
| 198*99*4.5*7 | 18.5 | 346*174*6*9 | 41.8 | 582*300*12*17 | 137 | 220*112*9.5 | 36.542 | 450*152*13.5 | 87.485 |
| 200*100*5.5*8 | 21.7 | 350*175*7*11 | 50 | 588*300*12*20 | 151 | 250*116*8 | 38.105 | 450*154*15.5 | 94.55 |
| 200*200*8*12 | 50.5 | 350*350*12*19 | 137 | 594*302*14*23 | 175 | 280*122*8.5 | 43.492 | 560*166*14.5 | 115.108 |
| 200*204*12*12 | 56.7 | 390*300*10*16 | 107 | 596*196*100*15 | 95.1 | 280*124*10.5 | 47.888 | 560*170*16.5 | 123.9 |
| 244*175*7*11 | 44.1 | 396*199*7*11 | 56.7 | 600*200*11*17 | 106 | 300*126*9 | 48.084 | 630*176*13 | 121.407 |
| 248*124*5*8 | 25.8 | 400*200*8*13 | 66 | 692*300*13*20 | 166 | 300*128*11 | 52.794 | 630*178*15 | 131.298 |
| 250*125*6*9 | 29.7 | 400*400*12*21 | 172 | 700*300*13*24 | 185 | 300*130*13 | 57.504 | 630*180*17 | 141.189 |
| 250*250*9*14 | 72.4 | 400*408*21*21 | 197 | 800*300*14*26 | 210 | 320*130*9.5 | 52.717 | ||
| 250*255*14*14 | 82.2 | 414*405*18*28 | 233 | 900*300*16*28 | 243 | 320*132*11.5 | 57.741 | ||
Material:S355JR,S355J0H,S355J2H,etc
Application:
1.Industrial structure of the steel structure bearing bracket.
2.Underground engineering steel pile and retaining structure.
3.Petrochemical and electric power and other industrial equipment structure
4.Large span steel bridge components
5.Ships, machinery manufacturing frame structure
6.The train, automobile, tractor beam bracket
7.Port of conveyor belt, high speed damper bracket
