Pre-Galvanized Steel Pipe Can Customer Made

Product Description

Pre-Galvanized Steel Pipe can customer made

I.Product Basic Info:

Shape:	round/sqaure/rectangular/oval or other special section tube
OD:	20-219.1mm, WT: 0.8-12mm
Size:	1010-400400mm,WT:0.8-12mm
Size:	1020-400600mm, WT:0.8-12mm
length:	0.3-13m (as customers' request)
Surface:	Pre-galvanized/Hot Dip Galvanized/Oiled/Painted/Bared , can be dealed as customers'need
Zinc Coating:	50-150g/m2 for Pre- galvanized, more than 200g/m2 for hot dip galvanized.or as clients'need
Material:	Q195/Q215/Q235/Q345/Q195-Q235 ABCD
Standard:	ASTM-A53 /BS 1387-1985/ GB/T 3091-2001 for round pipe
	ASTM A500 /GB/T3094 for square/rectangular pipe
Manufacturing Technique	Weld/Seamless/ ERW/ SSAW/ LSAW / Cold Drawn/ Hot Drawn
Ends:	Plain /Beveled/ Threaded with sockets coupling and plastic caps/ Necking down/ Expanding neck/ Punching holes

2.Product Chemical Composition & Mechanical Properties :

Grade	Chemical Composition					Mechanical Properties
	C	Mn	Si	S	P	Yield	Tensile	Elongati
	C	Mn	Si	S	P	Strength Mpa	Strenth Mpa	-on %
Q195	0.06-0.12	0.25-0.50	≤0.30	≤0.045	≤0.05	≥195	315-430	≥33
Q215	0.09-0.15	0.25-0.55	≤0.30	≤0.05	≤0.045	≥217	335-450	≥27
Q235	0.12-0.20	0.30-0.67	≤0.30	≤0.045	≤0.04	≥235	375-500	≥26
Q345	≤0.20	1.00-1.60	≤0.55	≤0.04	≤0.04	≥345	470-630	≥22

Now we are in the position to supply the tube as follows:
1. ERW Galv. Welded steel tube according to BS1387 or ASTM A53
2. Hot-dipped Galv. Scaffolding tube according to BS1139
3. Carbon seamless steel tube according to ASTM A53/A106/API 5L Gr. B
4. Seamless welded steel tube
5. Welded furniture tube with black surface or white surface condition

1)Outer Diameter: 21.3-219mm
2)Wall Thickness: 0.8-16mm
3)Spe.: Q195, Q215, Q235, Q345
4)Standard: ASTM-A53A, BS1387-1985, BG/T3091-2001
5)Steel pipe:
A)GTC(galvanized thread and coupling)steel pipe: DN15-DN200(NB1/2''-NB8'')
B)GPE(galvanized plan end)steel pipe: DN15-DN200
C)Grooved steel pipe: DN15-DN200(NB1/2''-NB8'')
D)Used for low pressure liquid apply such as water, gas and oil e)The product apply to various
Usage:Be widely used in furniture, building and construction Industry, traffic and communication, and so on.Special design available according to requirement
