Black API 5L ASTM A106 A53 Seamless Steel Pipe for Petroleum Pipeline Industrial

Product Description

Product Description

Product Name	Seamless steel pipe
Material	Carbon Steel and Alloy Steel
Surface	Oiled, Polished, Brightness, Metallic color
Standard	ASTM A106 A53 A192 A179 A210 A519 DIN17175 1629 2391 EN10216-1 10216-2 10305-1 and so on
Grade	St35,St45,St52,E215, E235,E355, sch10,sch20, A106,A179,A192,A210,T11,T22,T12,AISI4130, SAE1010,SAE1020.etc
Craft	Cold rolled and Cold drawn
Size	OD:8mm-100mm,WT:1-8mm
Length	Customized
Tolerance	Cold drawn pipe: +/-0.1mm Cold rolled pipe: +/-0.05mm
Used	Gas spring, Shock absorber, Cylinder and other high precision area

Usage of seamless pipe

According to production's technology and craft of steel tube, the steel pipes may separately be produced into basic two categories such as seamless steel pipe and welded steel pipe (Electric resistance welding pipe and Spiral welded pipe).
Seamless steel tube often could be formed and produced through hot rolled craft and cold drawn technology. Certainly the strength of hot rolled seamless steel pipes rather than cold drawn seamless steel tubes. About its common uses respectively are
Steam pipeline,
Gas pipeline,
Liquefied gas pipeline,
Natural gas pipelines,
All kinds of pipelines for petroleum products,
Pipelines for conveying various other gases or liquids.

Product Parameters

Standard: API5L PSL 1 & PSL 2 Steel Grade:GrB to X70 Size and OD: 1/2"-152"(21.3mm-3800mm) Wall Thickness: SCH10... STD,SCH40,SCH80...SCH160,XS,XXS.
Standard	Steel Grade	Chemical Components								Machanical Property
Standard	Steel Grade	C	Mn	Cr	Mo	P	S	Ni	Cu	Tensile Strength (Mpa)	Yield Strength(Mpa)
API Spec 5L PLS1	B	≤0.28	≤1.20	≤0.50	≤0.15	≤0.030	≤0.030	≤0.50	≤0.50	≥415	≥245
	X42	≤0.28	≤1.30	≤0.50	≤0.15	≤0.030	≤0.030	≤0.50	≤0.50	≥415	≥290
	X46	≤0.28	≤1.40	≤0.50	≤0.15	≤0.030	≤0.030	≤0.50	≤0.50	≥435	≥320
	X52	≤0.28	≤1.40	≤0.50	≤0.15	≤0.030	≤0.030	≤0.50	≤0.50	≥460	≥360
	X56	≤0.28	≤1.40	≤0.50	≤0.15	≤0.030	≤0.030	≤0.50	≤0.50	≥490	≥390
	X60	≤0.28	≤1.40	≤0.50	≤0.15	≤0.030	≤0.030	≤0.50	≤0.50	≥520	≥415
	X65	≤0.28	≤1.40	≤0.50	≤0.15	≤0.030	≤0.030	≤0.50	≤0.50	≥535	≥450
	X70	≤0.28	≤1.40	≤0.50	≤0.15	≤0.030	≤0.030	≤0.50	≤0.50	≥570	≥485
